Hatch
Hatch  button on the toolbar or [Draw > Hatch] menu command allows drawing a hatch.
| • | On the toolbar, click . Boundary Hatch and Fill dialog box will arise: |

| o | Select hatch name from the Pattern drop down list or press  Browse button to call hatches' collection (see Hatch Pattern Palette window above) |
| ▪ | By Layer - selected entity(ies) assumes the color assigned to the layer on which entity(ies) was created; |
| ▪ | By Block - selected entity(ies) assumes a color of the block which this entity belongs to. |
| o | Set Angle: angle = 0  ;angle = 15  |
| o | Set Scale: scale = 1  ; scale = 2  |
| • | Press  button and select bounding entity on the drawing (hold Ctrl button for selecting several entities). |
| • | Press Enter key and then  button on the arisen Boundary Hatch and Fill dialog box. |
Note:
|
